| Advantages |
|
Maximum
daily delivery trips possible |
| |
Minimum Labour
and resources required |
| |
Minimum maintenance
required |
| |
Zero damage
to goods |
| |
|
| Technical
Specifications |
|
Center gravity
of the load:600 mm |
|
|
Standard width
of the Platform : 2100 mm |
|
|
Standard Length
of the platform : 1800 mm |
| |
|
| |
|
| Electrical
Specifications: |
|
|
Motor voltage
: 12 Vdc Power :2 kw |
|
|
Rotation speed:
2600r/min |
|
Pump Displacement
: 2.5ml/r |
|
Voltage :12V |
|
Current :200A |
| |
|
| General
Specifications: |
|
High Quality
imported powerpack component |
|
Steel platform
(Aluminum platform available, at
extra cost) |
|
2 single acting
lift cylinder and 2 tilt cylinder |
|
Automatic Mechanical
Leveling |
|
Low maintenance
bushes fitted to all pivot points |
|
Mechanical
chain lock to prevent opening of
platform accidently |
| |
|
| Installation
Requirement |
|
| MODEL |
A
Min,Max. |
B
Min,Max. |
C
(Max) |
D
(Max) |
E
(Max) |
Chassis
width
(Max) |
INJ-15/130S
|
320,580
|
610,820 |
720 |
1300
|
200 |
880
|
| INJ-15/155S |
400,700 |
830,1040 |
850 |
1550 |
200 |
960 |
|
| |
| MODEL |
INJ-15/130S |
INJ-15/155S |
| Weight |
630kg |
630kg |
| Lifting capacity |
1500kg |
1500kg |
| Lifting height |
1300mm |
1550mm |
|
| |
|
